Entropia Riko

中文 | English

Entropia Riko is a professional node-graph deep-learning editor — ComfyUI-style visual workflows for PyTorch (and optional TensorFlow/Keras), with a modular Blender-like workspace, live training curves, code export, a plugin system, and a built-in file manager.

It runs as a web app (browser) and ships an Electron shell so you can use it as a standalone desktop app — you choose.

Install (PyPI)

pip install entropia-riko            # core + API server + PyTorch
pip install "entropia-riko[tf]"      # + TensorFlow/Keras nodes
pip install "entropia-riko[hf]"      # + Hugging Face (Diffusers/Transformers) nodes

Use it as a Python library:

import entropia_riko
import entropia_riko.nodes          # registers all 194 built-in nodes
from entropia_riko.runtime.registry import default_registry

print(entropia_riko.__version__)                  # "0.1.0"
print(len(default_registry().list()))             # 194

Or launch the API server:

entropia-riko                       # FastAPI on http://127.0.0.1:8000
# equivalent:
python -m uvicorn entropia_riko.server.app:app --port 8000

The pip package ships the Python runtime (nodes, executor, codegen, trainer, subgraphs, API server). The browser/Electron UI is not in the pip package — clone this repo for the full editor.

Features

• 200+ nodes — math, tensor ops, neural layers/activations, attention, normalization, reductions, shape ops, einsum, losses, data loaders, model inference, subgraph references, Hugging Face (Diffusers / Transformers), and TensorFlow/Keras equivalents.
• Node graph canvas (React Flow) — right-click search menu, drag to connect, custom node cards with live output previews.
• Modular Blender-style workspace — split/merge/resize any panel (drag the corner grip; both resulting rounded windows are previewed in blue), switch any window's type, multiple workspace tabs with presets (Layout / Code / Training / MNIST Studio / Text→Image / …).
• Code editor — a Notepad-style window (File/Edit menus + toolbar: New, Open, Save, Undo/Redo, Cut/Copy/Paste) for previewing/editing exported PyTorch code.
• Train + live loss curve — stream per-step loss (SSE) into an SVG chart.
• Train-to-model / load-from-model — save_model + model_loader file nodes (Houdini-style file picker on the path parameter) persist/restore model weights as safetensors or torch state_dicts.
• IDE-style project system — a folder is a project (project.riko manifest); 5 AI templates (Empty / CV / Diffusion / Audio / Video) generate a full structure (datasets/, models/, checkpoints/, workflows/, experiments/, …).
• Strong-typed ports — 18 data kinds (dataset, checkpoint, model, image_tensor, embedding, …); incompatible connections are rejected.
• Professional pipeline nodes — file_input, dataset, checkpoint_save/ checkpoint_load with project-relative paths.
• Reproducibility — bake/cache with provenance + experiment records (workflow/params/metrics/hardware) + multi-workflow dependency graph.
• Clean code export — PyTorch nn.Module and TensorFlow tf.keras.Model.
• Multi-file project export — File → Export Code → Export Project… writes a GitHub-layout PyTorch repo (README.md, requirements.txt, src/<name>.py) equivalent to the working folder.
• Subgraph navigation — double-click a graph_reference/import node to enter it; a Houdini-style breadcrumb (root / subgraph) in the top-left shows the level and exits back up.
• Multi-modal subgraph I/O — graph_input / graph_output accept a data_kind (tensor / text / json / image_tensor), not just numbers.
• Project-as-unit — work with a project folder (see templates/project/), not a single file; .riko/.ric files remain the on-disk format.
• Asset Library & New File — a working-directory file manager with drag-and-drop folders, right-click create/rename/delete, "expand full nodes" (inline a file's graph instead of a subgraph reference), and per-file PyTorch code preview.
• Built-in file explorer — Windows-style Import/Export (browse, back/forward, quick access, recent folders; copy files/folders instead of browser downloads).
• Plugin system — load plugins from .py files, toggle them on/off; managed in both a workspace panel and Preferences.
• Handwriting pad — draw a 28×28 digit and send it as a constant node to the MNIST example for inference.
• Themes — Light / Dark / System / Liquid Glass (Apple-style translucent).
• Detachable floating windows — all dialogs are draggable windows.
• Binary .ric format + ASCII .riko format with full metadata/settings.

Train → Save → Load → Infer

Models flow through the graph as model values and persist to disk via two file nodes (Houdini-style — the path parameter has a file picker):

• save_model (train-to-model) — serialize a model's state_dict to .safetensors (default) or .pt/.pth.
• model_loader (load-from-model) — load a state_dict back; set the module parameter (or feed a template) to rebuild the model structure and make it callable again.

/api/train also accepts save_path to persist the fitted model right after training. Example graphs ship in train + infer pairs (e.g. examples/models/cnn_train.riko + cnn_infer.riko), each showing the loop:

# 1) train the CNN and write cnn.safetensors
curl -X POST http://127.0.0.1:8000/api/train \
  -H "Content-Type: application/json" \
  -d '{"doc": <cnn_train.riko>, "steps": 20, "save_path": "cnn.safetensors"}'

# 2) run cnn_infer.riko — it loads cnn.safetensors and runs inference

Quick Start (browser)

cd entropia-riko
python -m venv .venv
. .venv/bin/activate            # Windows: .venv\Scripts\activate
pip install -r requirements.txt
npm install

# Terminal 1 — API (http://localhost:8000)
.venv/bin/python -m uvicorn entropia_riko.server.app:app --reload --port 8000

# Terminal 2 — frontend (http://localhost:5173)
npm run dev

Open http://localhost:5173 (the /api routes proxy to :8000).

Quick Start (desktop app)

The Electron shell spawns the backend and opens a native window on the Vite dev server:

npm install --save-dev electron
npm run dev &                # keep the Vite dev server running
npm run desktop

Set RIKO_DEV_URL to point at another frontend URL if needed.

.riko / .ric file format

.riko is human-readable JSON; .ric is the same document zlib-compressed behind an ERIK magic header. Both carry version, metadata (name, app, appVersion), nodes, edges, and settings (theme, background image). See docs/FILE_FORMAT.md.

Plugins

Plugins live in plugins/*/ (a plugin.json manifest + an entry Python module that registers nodes via @register). Load more from a .py file and toggle them from the Plugins panel or Preferences → Plugins. Disabled plugins are skipped so their nodes stay unregistered. Bundled examples: example_plugin, math_extra, stat_extra.

Development commands

.venv/bin/python -m unittest discover -s tests -t .   # Python tests
npm test                                              # frontend tests (vitest)
npm run build                                         # type-check + production build
npm run dev                                           # Vite dev server
npm run desktop                                       # Electron desktop shell
.venv/bin/python scripts/make_brand_assets.py         # brand asset helper (see script)

Distribution / Release

Package a clean, shareable source ZIP (commits pending changes, then archives only tracked files — no node_modules, .venv, dist, caches, or backups):

.venv/bin/python scripts/release.py "release note"

Output: entropia-riko-release.zip in the parent directory (the working folder is never modified). It contains entropia_riko/, public/, plugins/, examples/, templates/, electron/, scripts/, tests/, docs/, the READMEs, and config files — everything a recipient needs to pip install -r requirements.txt + npm install and run.

PyPI release

Build and publish the Python package (entropia-riko on PyPI):

.venv/bin/python -m pip install build twine
.venv/bin/python -m build --outdir dist-pypi
.venv/bin/python -m twine upload dist-pypi/*

Project structure

entropia_riko/
├── ui/         React app (canvas, panels, code editor, file manager, …)
├── core/       Tensor IR + graph document model (.riko/.ric)
├── runtime/    Registry, executor, PyTorch/TF codegen, trainer, subgraph
├── backend/    Torch device detection + conversion
├── nodes/      Node definitions
├── plugins/    Plugin loader
└── server/     FastAPI API server
plugins/        Bundled plugins
examples/       Ready-to-run pre-wired example graphs (dataset → model → loss → output)
electron/       Desktop shell (main + preload)
scripts/        Brand asset generator
public/brand/   logo.svg + hero.jpg (replace in place to rebrand)

Documentation

• User Guide — full manual (UI, nodes, training, export, API).
• docs/: APP_SPEC.md, APP_ARCHITECTURE.md, API.md, NODE_SYSTEM.md, DATA_FORMAT.md, FILE_FORMAT.md, UI_STANDARD.md, TORCH_BACKEND.md, CROSS_PLATFORM.md.

License

MIT
