TinyPPI Wiki

TinyPPI (script.tinyppi) is a Kodi add-on for CoreELEC that shows detailed, live playback information in its own overlay window while a video plays. It reads what the player, the Amlogic video driver and the stream's own side data report — video, audio, HDR10, HDR10+, HLG and Dolby Vision metadata, system load and more — and draws it over the picture without interrupting playback.

Around that overlay it adds a VS10 output-mode switcher, codec logos on the picture, a speaker-layout graphic, a full Dolby Vision metadata debugger and a web dashboard that mirrors everything to a phone or laptop on the same network.

Current version: 2.15.1 · Platform: CoreELEC 22 or later (Kodi 22, Amlogic) · License: AGPL-3.0-or-later

---

Feature overview

Feature	What it does	Page
TinyPPI overlay	Live player-process information over fullscreen video: display mode, resolution, pixel format, bit depth, aspect ratio, decoder, VS10 conversion, bitrate, media source, audio codec and layout, languages, CPU, temperature, memory, caches, HDR10 static metadata and Dolby Vision metadata	The TinyPPI Overlay
Dolby Vision metadata view	A live debug list of every block the Dolby Vision side data carries — configuration record, RPU header, composer, L1 to L255, static SEIs, HDR10+	Dolby Vision Metadata View
VS10 dialog	Switch the Amlogic VS10 engine's output (original, SDR, HDR10, Dolby Vision) for the playing title, in one of three dialog layouts	VS10 Output Modes
Codec logos	Video/HDR and audio format logos stacked on the picture on playback start, in the video OSD or alongside the overlay	Codec Logos
Channel layout graphic	A speaker diagram that lights up the channels the audio track carries (1.0 to 7.1.2)	Channel Layout Graphic
IMAX detection	Marks IMAX and IMAX Enhanced films by name, from a curated title list and your own additions	IMAX Detection
Themes and colors	Every color and opacity of every view is configurable through Kodi's color picker or a HEX code	Colors and Themes
Web dashboard	All readings, a live luminance chart, events, a remote, VS10 switching and the film/series library in the browser	Web Dashboard

---

Where to start

• New here? → Installation, then Getting Started.
• Want a remote button for it? → Launching and Keymaps.
• What does a row in the overlay mean? → The TinyPPI Overlay.
• Looking for one particular setting? → Settings Reference.
• Something does not work? → Troubleshooting and the FAQ.
• Want to automate it or build on it? → Dashboard HTTP API, Architecture and Development and Testing.

---

All pages

User guide

1. Installation
2. Getting Started
3. Launching and Keymaps
4. The TinyPPI Overlay
5. Dolby Vision Metadata View
6. VS10 Output Modes
7. Codec Logos
8. Channel Layout Graphic
9. IMAX Detection
10. Colors and Themes

Web dashboard

11. Web Dashboard
12. Dashboard Security
13. Dashboard HTTP API

Reference

14. Settings Reference
15. Troubleshooting
16. FAQ
17. Glossary

For developers

18. Architecture
19. Development and Testing
20. Translations

Project

21. License and Credits

---

Screenshots

Overlay (no conversion)	Overlay (VS10 conversion)	VS10 dialog

---

Links

• Source code: https://github.com/CE-Repo/script.tinyppi
• Add-on repository: https://ce-repo.github.io/repository.jamal2362/
• Dolby Vision / HDR parser: script.module.sidedata
